Bendix K101996 SLS Stop Lamp Switch, SL-4

Bendix Stop Lamp Switch K101996

• Genuine Bendix Switch K101996
• Replaces Bendix 276290
• Volvo part number 85142594
• Replaces Volvo 686339

Supply Port: 1/4-18 NPT
Thread Sealant: No Sealant
Connector Type: 1/4 SAE Type 1A Terminal
Terminal Post Size: #8-32 UNC-2A (2x)
Terminal Nut Included: Yes
Closing Pressure: 3-6 PSI
Current Rating: 10A (12V) / 5A (24V)
Body Material: Plastic
Maximum Operating Temperature: 200 °F (93 °C)
Minimum Operating Temperature: -40 °F (-40 °C)
Cautionary Note(s): Installation torque: 35-50 in-lbs.

Bendix K101996 Service Data
Bendix K101996 - Technical Attributes Guide
