Mack Truck 5396-40020234 Automatic Brake Adjuster
$298.18
$298.18
*41.4% Savings
$174.74
Automatic Brake Adjuster 5396-40020234 - Mack Truck
Replaces 21691670
Mack Truck 5396-40020234 - Automatic Brake Adjuster
Replaces 21691670
S-ABA Brake Adjuster
- High alloy steel gears
- Rolled wormshaft
- Heat-treated housing
- Centralized clutch
Notes
- The clearance-sensing design maintains a constant and uniform distance between the brake drum and lining.
- The gradual adjustment of the S-ABA lowers the risk of over-adjustment during prolonged braking.
- For Standard, Drive Axle Application.
TECHNICAL SPECS
| Spline Diameter-Spline Count | 1-1/2"-28 |
| Arm Length | 6" |
| Body Angle | 34° |
| Offset | 0 |
| Arm Hole Diameter | 1/2" |
| Bracket Kit | 42710553 |
| Anchor Bracket Style | Strap |
| OEM Part Number | 409-20023 |
| Grease Fitting Location | 180° |
| Grease Fitting Type | 45° |
