Continental 68208 Air Spring Rolling Lobe - Cross Reference Freightliner 16-19769-000
$155.89
Continental Air Spring Rolling Lobe 68208
- Equivalent to AB1DF23-9759
- Plastic Base
- For Aluminum Use 68207
Specifications:
| Type | Rolling Lobe |
| Automann Bellows# | 1DF23 |
| Firestone Bellows# | 1T15ZR-6 |
| Goodyear Bellows# | - |
| Contitech Bellows# | 9 10S-16 |
| Triangle Bellows# | 6300 |
| Load (Lbs) @80 PSI | 7900 |
| Load (Lbs) @100 PSI | 79 |
| Natural Freq. (CPM) | 12.50 |
| Bottom Plate Type | Plastic |
| Top Plate Hole/Stud Qty | 2 |
| Top Plate Dia. (A) | 9.00 |
| Top Plate C to C Dia. (B) | 6.22 |
| Bottom Plate Hole/Stud Qty | 1 |
| Bottom Plate Dia. (C) | N/A |
| Bottom Part # | BS12314 |
| Bottom Plate Alignment | - |
| Bumper | No |
| Bracket | N/A |
| Min. Height | 8.60 |
| Max. Height | 23.00 |
| Max. Dia. | 12.60 |
Â
Cross Reference:
- Contitech: 68208, 9 10S-16 P 224, 9 10S-16 P 999, 910S16P224, 910S-16P224
- Firestone: 9735, 9759, W013589759, W013779735, W01-377-9735, W013779759, W01-377-9759, 1T15ZR-6
- Freightliner: 1619769000, 16-19769-000, A1618335000, A16-18335-000, A1618335001, A16-18335-001, A1620111000, A16-20111-000
- Taurus: 6363
- Triangle: AS-8999P
